High throughput for greater efficiency
Applications such as the rewinding of tubes in copper tube production or the drawing of wire require a rotating sensor system with a high throughput. The Ro 20 F rotating head was developed especially for these applications. The powerful, multi-channel rotating head is designed for tubes, rods and wires with a material diameter of 2 - 20 mm. It enables the sensitive detection of longitudinal defects in the material surface. Defects from a depth of approx. 30 μm can be displayed in their full length and with high resolution.
Your advantages at a glance
- Max. throughput speed 6 m/s (Ro 20 F) Sensitive detection of longitudinal surface defects starting from a depth of approx. 30 μm
- Sensor system consisting of four sensors offset by 90°
- For testing ferromagnetic, austenitic and nonferromagnetic round material (tubes, rods, wires)
- Test heads available with 1.5 mm / 2.5 mm / 5 mm track width (analogous to sensor system Ro 20 P)
- Modular design enables easy replacement in existing lines
技术参数
Material diameter range:
| 2 - 20 mm (Ro 20 F) |
Throughput Speed (5 mm track width):
| 6 m/s (Ro 20 F) |
| Number of test heads: | 4 |
